Sea Sonic Electronics - Seasonic SS-300SFD Active PFC

Power supply (internal) - SFX12V 3.1 - 80 PLUS - AC 100-240 V - 300 Watt - active PFC

Sea Sonic Electronics
SS-300SFD
N/A
0882016000478
N/A
New

Price: $58.00

MSRP: $0.00
Total Available: 5

Product Description

Additional Details

What's Included

Specifications

Main Specifications
Product Description Seasonic SS-300SFD Active PFC - power supply - 300 Watt
Device Type Power supply - active Power Factor Correction (PFC) - internal
Specification Compliance SFX12V 3.1
80 PLUS Certification 80 PLUS
Input Voltage AC 100-240 V
Output Voltage +3.3, +5, ±12 V
Power Capacity 300 Watt
Output Current +3.3V - 20 A ¦ +5V - 20 A ¦ +12V1 - 8 A ¦ +12V2 - 14.5 A ¦ -12V - 0.8 A ¦ +5VSB - 2 A
Output connectors 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 4 pin ATX12V connector ¦ 1 x 15 pin Serial ATA power ¦ 1 x 4 pin internal power ¦ 1 x 4 pin mini-power connector
Cooling System 2 x 80 mm fans
Dimensions (WxDxH) 4.9 in x 3.9 in x 3 in
General
Device Type Power supply - active Power Factor Correction (PFC) - internal
Specification Compliance SFX12V 3.1
PSU Form Factor SFX
Miscellaneous
MTBF 100,000 hours
Cooling System 2 x 80 mm fans
Features Overvoltage protection, overpower protection, cold-start function, short-circuit protection, ball bearing cooling fan, non-modular
Compliant Standards UL, TUV, C-Tick, BSMI, ISO 9001, cUL, SEMKO, ISO 14001, CB, CCC, FCC, RoHS, WEEE
Environmental Parameters
Sound Emission 25 dBA
Power Device
Input Voltage AC 100-240 V
Frequency Required 50/60 Hz
Power Output Connectors Details 1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 4 pin ATX12V connector ¦ 1 x 15 pin Serial ATA power ¦ 1 x 4 pin internal power ¦ 1 x 4 pin mini-power connector
Output Voltage +3.3, +5, ±12 V
Power Capacity 300 Watt
Output Current +3.3V - 20 A ¦ +5V - 20 A ¦ +12V1 - 8 A ¦ +12V2 - 14.5 A ¦ -12V - 0.8 A ¦ +5VSB - 2 A
80 PLUS Certification 80 PLUS
Dimensions & Weight
Width 4.9 in
Depth 3.9 in
Height 3 in
