Hewlett Packard Enterprise - HPE ProLiant DL325 Gen10 Performance

Server - rack-mountable - 1U - 1-way - 1 x EPYC 7351P / 2.4 GHz - RAM 16 GB - SAS - hot-swap 2.5" - no HDD - GigE - monitor: none

Hewlett Packard Enterprise
P04647-B21
0190017285344
N/A

Price: CALL

Total Available: 8

Product Description

What's Included

Main Specifications
Product Description HPE ProLiant DL325 Gen10 Performance - rack-mountable - EPYC 7351P 2.4 GHz - 16 GB
Type Server - rack-mountable
Height (Rack Units) 1U
Server Scalability 1-way
Processor 1 x AMD EPYC 7351P / 2.4 GHz (2.9 GHz) (16-core)
Processor Socket Socket SP3
Cache Memory 64 MB L3 cache
Cache Per Processor 64 MB
RAM 16 GB (installed) / 2 TB (max) - DDR4 SDRAM - PC4-20800
Storage Controller RAID (SATA 6Gb/s / SAS 12Gb/s) - PCIe 3.0 x8 (HPE Smart Array E208i-a)
Server Storage Bays Hot-swap 2.5"
Hard Drive No HDD
Optical Storage No optical drive
Card Reader Yes
Video Memory 16 MB
Networking GigE
Power AC 120/230 V (50/60 Hz)
Power Redundancy Optional
Dimensions (WxDxH) 17.1 in x 24.2 in x 1.7 in
Weight 22.05 lbs
General
Type Server
Product Form Factor Rack-mountable - 1U
Built-in Devices LED panel, battery
Server Scalability 1-way
Hot-Swap Bays Qty 8
Expansion / Connectivity
Bays 1 (total) / 1 (free) x external ¦ 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots 1 (total) / 1 (free) x FlexibleLOM - three-quarter-length, full-height (low-profile) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 (low-profile) ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces 1 x HP iLO (1 in front) ¦ 5 x USB 3.0 (1 front, 2 rear, 2 internal) ¦ 4 x LAN (Gigabit Ethernet) (4 rear) ¦ 1 x HP iLO (1 rear) ¦ 1 x VGA (1 rear)
Miscellaneous
Included Accessories HPE Easy Install Rails
Compliant Standards AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
RAM
Installed Size 16 GB / 2 TB (max)
Technology DDR4 SDRAM
Effective Memory Speed 2666 MHz
Rated Memory Speed 2666 MHz
Memory Specification Compliance PC4-20800
Form Factor DIMM 288-pin
Slots 16 (total) / 14 (empty)
Features Registered, HPE SmartMemory
Configuration Features 2 x 8 GB
RAM Supported PC4-20800 - 2 TB Load-Reduced ¦ PC4-20800 - 1 TB registered
Networking
Ethernet Ports 4 x Gigabit Ethernet
Ethernet Controller HPE 331i
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller Integrated Lights-Out 5
Features Wake on LAN (WoL), PXE support
Power
Device Type Power supply - hot-plug
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Installed Qty 1
Max Supported Qty 2
Nominal Voltage AC 120/230 V (50/60 Hz)
Power Provided 500 Watt
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 8 - 90% (non-condensing)
Sound Emission 37 dBA
Storage Controller
Type 1 x RAID - PCIe 3.0 x8
Controller Interface Type SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name HPE Smart Array E208i-a
Channel Qty 8
RAID Level RAID 0, RAID 1, RAID 5, RAID 10
Cache Memory
Installed Size L3 cache - 64 MB
Cache Per Processor 64 MB
Optical Storage
Type No optical drive
Monitor
Monitor Type None.
Graphics Controller
Video Memory 16 MB
Video Interfaces VGA
Operating System / Software
OS Certified CentOS, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, SuSE Linux Enterprise Server 12 SP3, Red Hat Enterprise Linux 7.4, Red Hat Enterprise Linux 7.5, VMware vSphere 6.5 (ESXi) Update 2, VMware vSphere 6.7 (ESXi)
Hard Drive
Type No HDD
Dimensions & Weight
Width 17.1 in
Depth 24.2 in
Height 1.7 in
Weight 22.05 lbs
Card Reader
Type Card reader
Supported Flash Memory Cards microSD
Processor / Chipset
CPU AMD EPYC 7351P / 2.4 GHz
Max Turbo Speed 2.9 GHz
Number of Cores 16-core
CPU Qty 1
Max CPU Qty 1
CPU Upgradability Upgradable
CPU Socket Socket SP3
