VONNIC - VONNIC NVR-C302A-16/16P-4KS2
NVR - 16 channels - networked - 1U
VONNIC
NVR-C302A-16/16P-4KS2
N/A
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | VONNIC NVR-C302A-16/16P-4KS2 - standalone NVR - 16 channels |
| Device Type | NVR - 16 channels - networked - 1U |
| IP Cameras Supported | 16 |
| Compression Format | MJPEG, H.264, H.265 |
| Image Resolution | 1280x720, 1920x1080, 1280x1024, 3840x2160 |
| Hard Drive(s) Supported | Quantity: 2 - total capacity: 12 TB |
| Voltage | 120 / 230 V |
| Dimensions (WxDxH) | 37.5 cm x 32.7 cm x 5.3 cm |
| Weight | 4.4 kg |
| General | |
| Device Type | NVR - 1U |
| Video Channels | 16 |
| IP Cameras Supported | 16 |
| Image Resolution | 1280x720, 1920x1080, 1280x1024, 3840x2160 |
| Compression Format | MJPEG, H.264, H.265 |
| Networking | |
| Network Interfaces | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Supported Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, SNMP, HTTPS, UPnP, IPv4, IPv6, PPPoE |
| Power | |
| Voltage | 120 / 230 V |
| Frequency | 50/60 Hz |
| Power Consumption | 13.2 Watt |
| Environmental Parameters | |
| Min Operating Temperature | -10 °C |
| Max Operating Temperature | 55 °C |
| Humidity Range Operating | 10 - 90% |
| Hard Drive | |
| Quantity Supported | 2 |
| Interface | Serial ATA |
| Supported Max Total Capacity | 12 TB |
| Connections | |
| Video Input Ports | RJ-45 x 16 |
| Video Output Ports | HDMI x 1, VGA x 1 |
| Audio Input Ports | RCA x 1 |
| Audio Output Ports | RCA x 1 |
| Alarm Ports | Alarm input x 4, alarm output x 2 |
| Network Port | 10/100/1000Base-T |
| Other Ports | USB 2.0, serial RS-232 x 1, USB 3.0 x 1 |
| Dimensions & Weight | |
| Width | 37.5 cm |
| Depth | 32.7 cm |
| Height | 5.3 cm |
| Weight | 4.4 kg |
| Security DVR | |
| Display Modes | 9 split screens, full screen, 8 split screens, 16 split screens, 4 split screens |
| Playback Search | Date/time, event, time, motion detection |
| Record Events | Motion detection, scheduled, manual, continuous, tamper detection, video loss |
| Networked | Yes |
| Features | Pan/Tilt/Zoom support, motion detection, Power over Ethernet (PoE) |
