Dell - Dell EMC PowerEdge R540

Server - rack-mountable - 2U - 2-way - 1 x Xeon Silver 4110 / 2.1 GHz - RAM 16 GB - SAS - hot-swap 3.5" - HDD 1 TB - G200eR2 - GigE - no OS - monitor: none

Dell
RY04J
0884116321477
N/A
New

Price: CALL

MSRP: $5,089.85
Total Available: 0

Product Description

Additional Details

    What's Included

    Main Specifications
    Product Description Dell EMC PowerEdge R540 - rack-mountable - Xeon Silver 4110 2.1 GHz - 16 GB - 1 TB
    Type Server - rack-mountable
    Height (Rack Units) 2U
    Server Scalability 2-way
    Processor 1 x Intel Xeon Silver 4110 / 2.1 GHz (3 GHz) (8-core)
    Processor Socket FCLGA3647 Socket
    Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2
    Cache Memory 11 MB L3 cache
    Cache Per Processor 11 MB
    RAM 16 GB (installed) / 512 GB (max) - DDR4 SDRAM - ECC
    Storage Controller RAID (SAS 12Gb/s) (Dell PERC H730P)
    Server Storage Bays Hot-swap 3.5"
    Hard Drive 1 x 1 TB (hot-swap) - SATA 6Gb/s
    Optical Storage No optical drive
    Graphics Controller Matrox G200eR2
    Video Memory 16 MB
    Networking GigE
    Power AC 120/230 V (50/60 Hz)
    Power Redundancy Yes
    OS Provided No operating system
    Dimensions (WxDxH) 19 in x 26.8 in x 3.4 in
    Manufacturer Warranty Limited warranty - 3 years - on-site - response time: next business day
    General
    Type Server
    Product Form Factor Rack-mountable - 2U
    Server Scalability 2-way
    Hot-Swap Bays Qty 12
    Expansion / Connectivity
    Bays 12 (total) / 11 (free) x hot-swap 3.5"
    Slots 1 PCIe 3.0 x16 - full-height ¦ 3 PCIe 3.0 x16 - low-profile
    Interfaces LAN (Gigabit Ethernet) ¦ 1 x USB 2.0 - Type A (2 in front) ¦ 1 x management (NIC) ¦ 1 x USB 2.0 - micro-USB (1 in front) ¦ 1 x serial ¦ 2 x USB 3.0 - Type A (2 rear) ¦ 2 x VGA (1 front, 1 rear)
    Manufacturer Warranty
    Service & Support Limited warranty - 3 years - on-site - response time: next business day
    RAM
    Installed Size 16 GB / 512 GB (max)
    Technology DDR4 SDRAM - ECC
    Effective Memory Speed 2400 MHz
    Rated Memory Speed 2400 MHz
    Form Factor DIMM 288-pin
    Slots 16 (total) / 15 (empty)
    Features Registered
    Configuration Features 1 x 16 GB
    RAM Supported 512 GB registered - ECC ¦ 1 TB Load-Reduced - ECC
    Networking
    Interface (Bus) Type LAN-on-motherboard (LOM)
    Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
    Remote Management Controller Integrated Dell Remote Access Controller 9 Enterprise (iDRAC9)
    Power
    Device Type Power supply - hot-plug
    Power Redundancy Yes
    Power Redundancy Scheme 1+1
    Installed Qty 2
    Max Supported Qty 2
    Nominal Voltage AC 120/230 V (50/60 Hz)
    Power Provided 750 Watt
    Environmental Parameters
    Min Operating Temperature 50 °F
    Max Operating Temperature 95 °F
    Humidity Range Operating 10 - 80%
    Storage Controller
    Type 1 x RAID
    Controller Interface Type SAS 12Gb/s
    Storage Controller Name Dell PERC H730P
    RAID Level RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
    Cache Memory
    Installed Size L3 cache - 11 MB
    Cache Per Processor 11 MB
    Optical Storage
    Type No optical drive
    Monitor
    Monitor Type None.
    Graphics Controller
    Graphics Processor Matrox G200eR2
    Video Memory 16 MB
    Video Interfaces VGA
    Operating System / Software
    OS Provided No operating system
    Hard Drive
    Type HDD - hot-swap
    Capacity 1 x 1 TB
    Interface Type SATA 6Gb/s
    Dimensions & Weight
    Width 19 in
    Depth 26.8 in
    Height 3.4 in
    Processor / Chipset
    CPU Intel Xeon Silver 4110 / 2.1 GHz
    Max Turbo Speed 3 GHz
    Number of Cores 8-core
    CPU Qty 1
    Max CPU Qty 2
    CPU Upgradability Upgradable
    Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2
    CPU Socket FCLGA3647 Socket
