Super Micro Computer - Supermicro CloudDC SuperServer 120C-TN10R
Server - rack-mountable - 1U - 2-way - no CPU up to - RAM 0 GB - SATA/PCI Express - hot-swap 2.5" bay(s) - no HDD - AST2600 - no OS - monitor: none - black, silver
Super Micro Computer
SYS-120C-TN10R
0672042421664
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Supermicro CloudDC SuperServer 120C-TN10R - rack-mountable no CPU - 0 GB - no HDD |
| Type | Server - rack-mountable |
| Height (Rack Units) | 1U |
| Server Scalability | 2-way |
| Processor | No CPU |
| Processor Socket | LGA4189 Socket |
| RAM | 0 GB (installed) / 6 TB (max) - DDR4 SDRAM - ECC |
| Storage Controller | RAID (SATA 6Gb/s); NVMe |
| Server Storage Bays | Hot-swap 2.5" |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | ASPEED AST2600 |
| Power Redundancy | Yes |
| OS Provided | No operating system |
| Color | Black, silver |
| Dimensions (WxDxH) | 17.2 in x 23.5 in x 1.7 in |
| Weight | 24.91 lbs |
| Manufacturer Warranty | Limited warranty - parts - 1 year ¦ Limited warranty - labor - 3 years |
| General | |
| Type | Server |
| Product Form Factor | Rack-mountable - 1U |
| Server Scalability | 2-way |
| Hot-Swap Bays Qty | 10 |
| Color | Black, silver |
| Expansion / Connectivity | |
| Bays | 10 (total) / 10 (free) x hot-swap 2.5" |
| Slots | 2 (total) / 2 (free) x PCIe 4.0 x16 (full-height, half-length) ¦ 2 (total) / 2 (free) x M.2 Card - 2280 (Key M) |
| Interfaces | 1 x management (NIC) - RJ-45 ¦ 2 x USB 3.0 ¦ 1 x VGA ¦ 2 x USB 2.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts - 1 year ¦ Limited warranty - labor - 3 years |
| Miscellaneous | |
| Included Accessories | 2 x CPU Heatsink, 2 x air shrouds |
| RAM | |
| Installed Size | 0 GB (installed) / 6 TB (max) |
| Technology | DDR4 SDRAM - ECC |
| Form Factor | DIMM 288-pin |
| Slots | 16 (total) / 16 (empty) |
| Features | Registered, Load-Reduced DIMM (LRDIMM), supports Intel Optane DC Persistent Memory (DCPMM) |
| Networking | |
| Remote Management Protocol | IPMI 2.0 |
| Features | ACPI support, KVM over IP support |
| Power | |
| Device Type | Power supply |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Voltage Required | AC 100-240/ DC 200-240 V |
| Power Provided | 860 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 8 - 90% (non-condensing) |
| Storage Controller | |
| Type | 1 x RAID |
| Controller Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | ASPEED AST2600 |
| Video Interfaces | VGA |
| Operating System / Software | |
| OS Provided | No operating system |
| Storage Controller (2nd) | |
| Type | 1 x NVMe |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 23.5 in |
| Height | 1.7 in |
| Weight | 24.91 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 23.8 in |
| Shipping Depth | 32.4 in |
| Shipping Height | 7.8 in |
| Shipping Weight | 39.9 lbs |
| Processor / Chipset | |
| CPU | No CPU |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| CPU Socket | LGA4189 Socket |
| Chipset Type | Intel C621A |
| Motherboard Name | Supermicro X12DDW-A6 |
