Avaya - Avaya Scopia XT7100
Video conferencing kit - TAA Compliant
Avaya
55511-00401
N/A
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Avaya Scopia XT7100 - video conferencing kit - TAA Compliant |
| Device Type | Video conferencing kit |
| VoIP Protocols | H.323, SIP, RTP, SRTP |
| Codec | H.263, H.263+, H.264, H.265, H.263++, H.239, G.711, G.722, G.728, G.729a, G.722.1, G.722.1c, AAC-LD, AAC-LC |
| Max Transfer Rate | 6 Mbps |
| Digital Signaling Protocol | H.323, H.281, H.320, SIP, H.239, H.231, H.243, H.245, H.460.18, H.460.19, H.224 |
| Data Compression Protocol | H.350, H.235 ver 3 |
| Features | Echo cancellation, DTMF decoding |
| Video Input | Digital video camera - RS-232 |
| Video Output | Codec board |
| Audio Input | Microphone |
| Audio Output | Sound card |
| Input Device | Remote control (wireless) |
| Networking | Network adapter - Ethernet, Fast Ethernet, Gigabit Ethernet |
| Power | AC 120/230 V (50/60 Hz) |
| TAA Compliant | Yes |
| General | |
| Device Type | Video conferencing kit |
| VoIP Protocols | H.323, SIP, RTP, SRTP |
| Voice Codecs | G.711, G.722, G.728, G.729a, G.722.1, G.722.1c, AAC-LD, AAC-LC |
| Video Codecs | H.263, H.263+, H.264, H.265, H.263++, H.239 |
| Security | 128-bit AES, 256-bit AES, EAP-MD5, TLS |
| Network Protocols | HTTP, HTTPS, RTCP, RTP, SNTP |
| Dimensions & Weight Details | Main system - Width 11.4 in Depth 6.5 in Height 1.6 in Weight 3.3 lbs ¦ Camera - Width 9.8 in Depth 5.3 in Height 6 in Weight 3.5 lbs ¦ Microphone - Width 5.3 in Weight 15.9 oz |
| Expansion / Connectivity | |
| Interfaces | 2 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x display / video - DVI-Analog/Digital input - 24+5 pin combined DVI ¦ 1 x camera - RS-232 - 8 pin mini-DIN ¦ 1 x USB 2.0 - 4 pin USB Type A ¦ 1 x SuperSpeed USB 3.0 - 9 pin USB Type A ¦ 2 x audio / video - HDMI output - 19 pin HDMI Type A ¦ 2 x audio / video - HDMI input - 19 pin HDMI Type A ¦ 1 x microphone - input - RJ-11 ¦ 1 x audio - input - mini-phone 3.5 mm ¦ 1 x audio - output - mini-phone 3.5 mm |
| Miscellaneous | |
| Compliant Standards | SHA-512, RSA-4096 |
| TAA Compliant | Yes |
| Networking | |
| Type | Network adapter |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Network / Transport Protocol | TCP/IP, DHCP, DNS |
| Features | Flow control, NAT support, LDAP support, DiffServ support, IPv6 support, full duplex mode, firmware upgradable, Trivial File Transfer Protocol (TFTP) support, Quality of Service (QoS), IP Precedence, SSH support, IPv4 support, automatic gain control (AGC), Type of Service (ToS) |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1x |
| Power | |
| Power Device | Power supply - internal |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Audio Output | |
| Type | Sound card |
| Audio Input | |
| Type | Microphone - external |
| Input Device | |
| Type | Remote control |
| Connectivity Technology | Wireless |
| Modem | |
| Type | Wired |
| Max Transfer Rate | 6 Mbps |
| Digital Signaling Protocol | H.323, H.281, H.320, SIP, H.239, H.231, H.243, H.245, H.460.18, H.460.19, H.224 |
| Data Compression Protocol | H.350, H.235 ver 3 |
| Features | Echo cancellation, DTMF decoding |
| Video Input | |
| Type | Digital video camera (color) - external |
| Interface Type | RS-232 |
| Digital Video Capture Resolution | 1280 x 720, 720 x 480, 352 x 240, 640 x 480, 1280 x 960, 1024 x 768, 352 x 288, 720 x 576, 704 x 576, 704 x 480, 1280 x 1024, 800 x 600, 1280 x 768, 1920 x 1080, 848 x 480, 1024 x 576, 1280 x 800, 1440 x 900, 1600 x 900, 512 x 288, 768 x 448, 624 x 352, 416 x 240, 576 x 336, 400 x 224 |
| Video Output | |
| Type | Codec board - desktop |
| Supported Display Graphics | HDTV (1920x1080), HD (1280 x 720) |
| Digital Video Standard | High-Definition Multimedia Interface (HDMI) |
