Intel HD Graphics 530 Dynamic Video Memory Technology 5.0
Networking
1GbE
Keyboard
US
Power
AC 120/230 V (50/60 Hz)
OS Provided
Microsoft Windows 7 Professional (downgrade from Windows 10 Pro 64-bit) + Windows 10 Pro 64-bit License
Color
Black
Dimensions (WxDxH)
13.3 in x 15 in x 3.9 in
Weight
12.57 lbs
Pricing Type
Promo
Environmental Standards
ENERGY STAR Qualified
Manufacturer Warranty
Limited warranty - parts and labor - 3 years - on-site
General
Platform Technology
Intel vPro Platform
Type
Workstation
Product Form Factor
Small form factor
Built-in Devices
Hood sensor, solenoid lock
Embedded Security
Trusted Platform Module (TPM 1.2) Security Chip
Color
Black
Localization
Language: English / region: United States
Expansion / Connectivity
Bays
1 (total) / 0 (free) x external 5.25" Slim Line ¦ 1 (total) / 1 (free) x 3.5" ¦ 1 (total) / 0 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5"
Slots
1 (total) / 0 (free) x CPU ¦ 4 (total) / 3 (free) x DIMM 288-pin ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, low-profile ¦ 2 (total) / 2 (free) x PCIe 3.0 x1 - half-length, low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, low-profile (x4 mode) ¦ 1 (total) / 1 (free) x M.2 Card (x4 mode)
Interfaces
8 x USB 3.0 (2 front, 6 rear) ¦ 2 x USB 2.0 (2 in front) (one of them is charging data port) ¦ 1 x headphones (1 in front) ¦ 1 x headphones/microphone (1 in front) ¦ 3 x DisplayPort ¦ 1 x serial ¦ 1 x PS/2 keyboard ¦ 1 x PS/2 mouse ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x audio line-in ¦ 1 x audio line-out
Manufacturer Warranty
Service & Support
Limited warranty - parts and labor - 3 years - on-site
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, WEEE, Common Criteria EAL4+, ACPI 4.0, low halogen
Pricing Type
Promo
RAM
Installed Size
8 GB / 64 GB (max)
Technology
DDR4 SDRAM - non-ECC
Effective Memory Speed
2133 MHz
Rated Memory Speed
2133 MHz
Form Factor
DIMM 288-pin
Slots
4 (total) / 3 (empty)
Features
Unbuffered, dual channel memory architecture
Configuration Features
1 x 8 GB
Networking
Ethernet Controller
Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Wake on LAN (WoL), ACPI support, PXE support, auto-uplink (auto MDI/MDI-X)
