Elo Touch Solutions - Elo X-Series Touchcomputer ESY20X5

All-in-one - 1 x Core i5 6500TE - RAM 4 GB - SSD 128 GB - HD Graphics 530 - GigE - WLAN: Bluetooth 4.0, 802.11a/b/g/n/ac - Windows 10 - monitor: LED 19.5" 1920 x 1080 (Full HD) touchscreen

Elo Touch Solutions
E549423
N/A
0815335027826
N/A

Price: $1,785.00

MSRP: $2,068.00
Total Available: 1

Product Description

What's Included

Main Specifications
Product Description Elo X-Series Touchcomputer ESY20X5 - all-in-one - Core i5 6500TE - 4 GB - 128 GB - LED 19.5"
Type Kiosk - all-in-one
Localization Region: Worldwide
Processor 1 x Intel Core i5 (6th Gen) 6500TE (3.3 GHz) (Quad-Core)
Processor Main Features Intel Turbo Boost Technology 2, Intel Smart Cache
Cache Memory 6 MB L3 cache
Cache Per Processor 6 MB
RAM 4 GB (installed) / 16 GB (max) - DDR4 SDRAM
Storage Controller SATA
Hard Drive 1 x SSD 128 GB - SATA
Optical Storage No optical drive
Monitor 19.5" - LED - 1920 x 1080 (Full HD) - 16:9 - touchscreen
Graphics Controller Intel HD Graphics 530
Audio Output Stereo
Networking GigE, 802.11a, 802.11b/g/n, Bluetooth 4.0, 802.11ac
Power AC 120/230 V (50 - 60 Hz)
OS Provided Windows 10
Color Black
Dimensions (WxDxH) 19.4 in x 9.9 in x 14.1 in
Weight 16.6 lbs
Environmental Standards ENERGY STAR Qualified
Manufacturer Warranty Limited warranty - 3 years
General
Type Kiosk
Product Form Factor All-in-one
Color Black
Localization Region: Worldwide
Expansion / Connectivity
Interfaces 2 x USB 3.0 ¦ 7 x USB 2.0 ¦ 1 x serial ¦ 1 x serial - RJ-45 ¦ 2 x VGA output ¦ 1 x DisplayPort output ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x PoweredUSB (24 V) ¦ 1 x cash drawer
Manufacturer Warranty
Service & Support Limited warranty - 3 years
Miscellaneous
Theft/Intrusion Protection Security lock slot (cable lock sold separately)
VESA Mounting Interface 100 x 100 mm
Compliant Standards UL, TUV, VCCI, C-Tick, cUL, CB, CCC, FCC, S Mark, Mexico CoC
RAM
Installed Size 4 GB / 16 GB (max)
Technology DDR4 SDRAM
Effective Memory Speed 2133 MHz
Rated Memory Speed 2133 MHz
Slots 2 (total) / 1 (empty)
RAM Supported PC4-19200 - 16 GB
Networking
Wireless LAN Supported Yes
Data Link Protocol Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0, IEEE 802.11ac
Power
Device Type Power adapter
Nominal Voltage AC 120/230 V (50 - 60 Hz)
Power Consumption Operational 75 Watt
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 95 °F
Humidity Range Operating 20 - 80% (non-condensing)
Storage Controller
Type SATA
Cache Memory
Installed Size L3 cache - 6 MB
Cache Per Processor 6 MB
Optical Storage
Type No optical drive
Monitor
Monitor Type LED
Touchscreen Yes (10-point multi-touch)
Diagonal Size 19.5"
Native Resolution 1920 x 1080 (Full HD)
Widescreen Display Yes
Image Aspect Ratio 16:9
Horizontal Viewing Angle 178
Vertical Viewing Angle 178
Response Time 20 ms
Image Brightness 212.5 cd/m²
Image Contrast Ratio 3000:1
Monitor Features Anti-glare, Zero-Bezel Design, Projected Capacitive Touch (P-CAP) technology
Graphics Controller
Graphics Processor Intel HD Graphics 530
Audio Output
Sound Output Mode Stereo
Speakers Included 2 x right / left channel
Operating System / Software
OS Provided Windows 10
Hard Drive
Type SSD
Capacity 1 x 128 GB
Interface Type SATA
Dimensions & Weight
Dimensions & Weight Details 19.4 in - 2.6 in - 12.6 in - 10.9 lbs - without stand ¦ 19.4 in - 9.9 in - 14.1 in - 16.6 lbs - with stand
Width 19.4 in
Depth 9.9 in
Height 14.1 in
Weight 16.6 lbs
Dimensions & Weight (Shipping)
Shipping Width 27.2 in
Shipping Depth 17.5 in
Shipping Height 14.4 in
Shipping Weight 25.86 lbs
Environmental Standards
ENERGY STAR Certified Yes
Processor / Chipset
CPU Intel Core i5 (6th Gen) 6500TE
Max Turbo Speed 3.3 GHz
Number of Cores Quad-Core
CPU Qty 1
Max CPU Qty 1
Processor Main Features Intel Turbo Boost Technology 2, Intel Smart Cache
Chipset Type Intel Q170 Express
