Intel Core i7 9850H / 2.6 GHz - vPro - Win 10 Pro 64-bit - Quadro T2000 - 32 GB RAM - 1 TB SSD NVMe, Class 40 - 15.6" touchscreen 3840 x 2160 (Ultra HD 4K) - Wi-Fi 5 - platinum silver - BTS - with 1 Year Dell Hardware Service with Onsite/In-Home Service After Remote Diagnosis
| Main Specifications | |
|---|---|
| Product Description | Dell Precision 5540 - 15.6" - Core i7 9850H - vPro - 32 GB RAM - 1 TB SSD |
| Product Type | Mobile workstation |
| Operating System | Win 10 Pro 64-bit |
| Platform Technology | Intel vPro Platform |
| Processor | Intel Core i7 (9th Gen) 9850H / 2.6 GHz (4.6 GHz) / 12 MB Cache |
| Memory | 32 GB DDR4 (2 x 16 GB) |
| Storage | 1 TB SSD - NVMe, Class 40 |
| Display | 15.6" touchscreen 3840 x 2160 / Ultra HD 4K - 282 ppi |
| Graphics | NVIDIA Quadro T2000 |
| Video Memory | 4 GB GDDR5 SDRAM |
| Input Device | Keyboard, touchpad |
| Keyboard Backlight | Yes |
| Integrated Webcam | Yes |
| Networking | 802.11a/b/g/n/ac Wave 2, Bluetooth 5.0, Ethernet |
| Battery | 6-cell |
| Security | Trusted Platform Module (TPM 2.0) Security Chip, fingerprint reader |
| Color | Platinum silver |
| Dimensions (WxDxH) | 14.1 in x 9.3 in x 0.4 in |
| Weight | 3.97 lbs |
| Pricing Type | Build To Stock (BTS) |
| Environmental Standards | ENERGY STAR Qualified |
| Bundled Services | 1 Year Dell Hardware Service with Onsite/In-Home Service After Remote Diagnosis |
| General | |
| Product Type | Mobile workstation |
| Operating System | Windows 10 Pro 64-bit Edition |
| Memory | |
| RAM | 32 GB (2 x 16 GB) |
| Max RAM Supported | 64 GB |
| Technology | DDR4 SDRAM - non-ECC |
| Speed | 2666 MHz |
| Rated Speed | 2666 MHz |
| Form Factor | SO-DIMM 260-pin |
| Slots Qty | 2 |
| Empty Slots | 0 |
| Manufacturer Warranty | |
| Bundled Services | 1 Year Dell Hardware Service with Onsite/In-Home Service After Remote Diagnosis |
| Miscellaneous | |
| Color | Platinum silver |
| Security | Trusted Platform Module (TPM 2.0) Security Chip, fingerprint reader |
| Features | ExpressCharge |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Noble Wedge security slot |
| Included Accessories | Power adapter |
| Pricing Type | Build To Stock (BTS) |
| Storage | |
| Main Storage | 1 TB SSD M.2 PCIe - NVM Express (NVMe), Class 40 |
| Software | |
| Software Included | Microsoft Office (30 days trial), Dell Precision Optimizer |
| Battery | |
| Technology | 6-cell lithium ion |
| Capacity | 97 Wh |
| Display | |
| Type | 15.6" |
| Touchscreen | Yes |
| Resolution | 3840 x 2160 (Ultra HD 4K) |
| Widescreen | Yes |
| Pixel Density (ppi) | 282 |
| Image Aspect Ratio | 16:9 |
| Color Gamut | 100% sRGB |
| Features | UltraSharp, Premium Panel Guarantee, IGZO technology, ±89° horizontal viewing angle, ±89° vertical viewing angle, 0.09 mm pixel pitch |
| Communications | |
| Wireless | 802.11a/b/g/n/ac Wave 2, Bluetooth 5.0 |
| Wireless Controller | Intel Wireless-AC 9260 |
| Network Interface | Ethernet |
| Features | Wake-on-LAN (WOL) |
| Dimensions & Weight | |
| Dimensions (WxDxH) | 14.1 in x 9.3 in x 0.4 in |
| Weight | 3.97 lbs |
| Environmental Standards | |
| ENERGY STAR Certified | Yes |
| Processor / Chipset | |
| CPU | Intel Core i7 (9th Gen) 9850H / 2.6 GHz |
| Max Turbo Speed | 4.6 GHz |
| Number of Cores | 6-core |
| Cache | 12 MB |
| 64-bit Computing | Yes |
| Platform Technology | Intel vPro Platform |
| Features | Intel Turbo Boost Technology 2.0 |
| Audio & Video | |
| Graphics Processor | NVIDIA Quadro T2000 |
| Video Memory | 4 GB GDDR5 SDRAM |
| Camera | Yes - HD |
| Resolution | 0.92 Megapixel |
| Video Resolutions | 1280 x 720 |
| Frame Rate | 30 frames per second |
| Camera Features | 66 degrees |
| Sound | Stereo speakers, dual array microphone |
| Audio Features | MaxxAudio Pro |
| Input | |
| Type | Keyboard, touchpad |
| Keyboard Backlight | Yes |
| Features | Multi-touch touchpad |
| AC Adapter | |
| Input | AC 120/230 V (50/60 Hz) |
| Output | 130 Watt, 19.5 V, 6.67 A |
| Connections & Expansion | |
| Interfaces | Headphone/microphone combo jack ¦ 2 x USB 3.1 Gen 1 (PowerShare) ¦ USB-C 3.1 Gen 2 (supports Thunderbolt 3) (Power Delivery) ¦ LAN (on supplied adapter) ¦ HDMI |
| Memory Card Reader | Yes (SD Card) |
