Server - rack-mountable 2U - 2-way - 1 x EPYC 9124 / up to 3.7 GHz - RAM 32 GB - SATA/SAS/NVMe - hot-swap 2.5" bay(s) - no HDD - Gigabit Ethernet - monitor: none
| Main Specifications | |
|---|---|
| Product Description | HPE ProLiant DL385 Gen11 - rack-mountable EPYC 9124 3 GHz - 32 GB - no HDD |
| Type | Server - rack-mountable |
| Height (Rack Units) | 2U |
| Localization | Region: Japan |
| Server Scalability | 2-way |
| Processor | 1 x AMD EPYC 9124 / 3 GHz (up to 3.7 GHz, (16-core) |
| Cache Memory | 64 MB L3 cache |
| Cache Per Processor | 64 MB |
| RAM | 32 GB (installed) / 6 TB (max) - DDR5 SDRAM |
| Storage Controller | RAID OCP (HPE MR408i-o Gen11 SPDM) |
| Server Storage Bays | Hot-swap 2.5" |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Video Memory | 16 MB |
| Networking | 1GbE |
| Power | (50/60 Hz) |
| Power Redundancy | Optional |
| Dimensions (WxDxH) | 17.1 in x 25.4 in x 3.4 in |
| Weight | 36.99 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | Limited warranty - parts and labor - 3 years - on-site - response time: next business day |
| General | |
| Type | Server |
| Product Form Factor | Rack-mountable - 2U |
| Built-in Devices | LED panel |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability | 2-way |
| Hot-Swap Bays Qty | 8 |
| Localization | Region: Japan |
| Expansion / Connectivity | |
| Bays | 8 (total) / 8 (free) x hot-swap 2.5" SFF |
| Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 (x16 mode) |
| Interfaces | 1 x HPE iLO (1 in front) (service port) ¦ 1 x HPE iLO - RJ-45 (1 rear) (management port) ¦ 5 x USB 3.2 Gen 1 (1 front, 2 rear, 2 internal) ¦ 4 x LAN (Gigabit Ethernet) ¦ 1 x VGA |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site - response time: next business day |
| Miscellaneous | |
| Included Accessories | 6 x standard fans |
| Compliant Standards | AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1 |
| RAM | |
| Installed Size | 32 GB (installed) / 6 TB (max) |
| Technology | DDR5 SDRAM |
| Effective Memory Speed | 4800 MHz |
| Rated Memory Speed | 4800 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 24 (total) / 23 (empty) |
| Features | Registered, HPE SmartMemory, slots 13 - 24 are available in two-processor configuration only |
| Configuration Features | 1 x 32 GB |
| Networking | |
| Interface (Bus) Type | Open Compute Project mezzanine (OCP) 3.0 |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Ethernet Controller | Broadcom BCM5719 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0, SNMP 3 |
| Remote Management Controller | Integrated Lights-Out 6 |
| Features | Wake on LAN (WoL), PXE support |
| Power | |
| Device Type | Power supply - hot-plug |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Voltage Required | AC 100-120/200-240 V (50/60 Hz) |
| Power Provided | 800 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 8 - 90% RH (non-condensing) |
| Storage Controller | |
| Type | 1 x RAID - OCP |
| Storage Controller Name | HPE MR408i-o Gen11 SPDM |
| Channel Qty | 8 |
| Buffer Size | 4 GB |
| Cache Memory | |
| Installed Size | L3 cache - 64 MB |
| Cache Per Processor | 64 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Video Memory | 16 MB |
| Video Interfaces | VGA |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 17.1 in |
| Depth | 25.4 in |
| Height | 3.4 in |
| Weight | 36.99 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 23.6 in |
| Shipping Depth | 36.1 in |
| Shipping Height | 10.6 in |
| Shipping Weight | 57.76 lbs |
| Processor / Chipset | |
| CPU | AMD EPYC 9124 |
| Clock Speed | 3 GHz |
| Max Turbo Speed | 3.7 GHz |
| Number of Cores | 16-core |
| CPU Qty | 1 |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 3.0 |
