Simply NUC - Simply NUC Emerald NUC11EMi7
Mini PC Core i7 1165G7 / up to 4.7 GHz - RAM 32 GB - SSD 1 TB - NVMe - Intel Iris Xe Graphics - Gigabit Ethernet - Win 10 Pro 64-bit - monitor: none
Simply NUC
91A-YAG4-001
N/A
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Simply NUC Emerald NUC11EMi7 - mini PC Core i7 1165G7 - 32 GB - SSD 1 TB |
| Type | Personal computer - mini PC |
| Processor | Intel Core i7 (11th Gen) 1165G7 (up to 4.7 GHz, (Quad-Core) |
| Processor Main Features | Intel Turbo Boost Technology |
| Cache Memory | 12 MB |
| Cache Per Processor | 12 MB |
| RAM | 32 GB (installed) / 64 GB (max) - DDR4 SDRAM |
| Storage Controller | SATA/NVMe (SATA 6Gb/s / PCIe 3.0 x4 (NVMe)) |
| Hard Drive | SSD 1 TB - PCI Express 3.0 x4 - M.2 2280 - NVM Express (NVMe) |
| Optical Storage | No optical drive |
| Card Reader | Yes |
| Graphics Controller | Intel Iris Xe Graphics |
| Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, 802.11ax, Bluetooth 5.1 |
| OS Provided | Windows 10 Pro 64-bit Edition |
| Dimensions (WxDxH) | 6.6 in x 4.5 in x 1.5 in |
| Manufacturer Warranty | Limited warranty - 1 year |
| General | |
| Type | Personal computer |
| Product Form Factor | Mini PC |
| Expansion / Connectivity | |
| Slots | 1 (total) / 0 (free) x M.2 Card - 2280 (Key M) ¦ 1 (total) / 1 (free) x M.2 Card - 2242 (Key B) |
| Interfaces | 2 x USB 3.2 - Type A ¦ 1 x DisplayPort 1.4a/USB4 ¦ 1 x headphones/microphone - mini-jack ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x LAN (2.5Gigabit Ethernet) - RJ-45 ¦ 2 x USB 2.0 - Type A ¦ 3 x HDMI |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Included Accessories | VESA mounting kit |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| Compliant Standards | IEC 60950-1, IEC 62321-1:2013, IEC 62321-2:2013, IEC 62321-3:2013, IEC 62321-4:2013, IEC 62321-5:2013, IEC 62321-6:2015, IEC 62321-7:2015, IEC 62321-7:2017, IEC 62321-8:2017, EN 60950-1, EN 55032, EN 61000-3, EN 62311, EN55024, ETSI EN 300 328, ETSI EN 300 440, ETSI EN 301 489-1, ETSI EN 301 489-17, ETSI EN 301 489-3, ETSI EN 301 893, FCC CFR47 Part 15 B, FCC CFR47 Part 15 C, FCC CFR47 Part 15 E, RoHS, REACH |
| RAM | |
| Installed Size | 32 GB (installed) / 64 GB (max) |
| Technology | DDR4 SDRAM |
| Effective Memory Speed | 3200 MHz |
| Form Factor | SO-DIMM 260-pin |
| Networking | |
| Ethernet Ports | 1 x 2.5 Gigabit Ethernet, 1 x Gigabit Ethernet |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6 AX 201 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax, Bluetooth 5.1 |
| Power | |
| Device Type | Power adapter |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Storage Controller | |
| Type | SATA/NVMe |
| Controller Interface Type | SATA 6Gb/s / PCIe 3.0 x4 (NVMe) |
| Channel Qty | 2 |
| Cache Memory | |
| Installed Size | 12 MB |
| Cache Per Processor | 12 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel Iris Xe Graphics |
| Video Interfaces | HDMI, USB-C |
| Operating System / Software | |
| OS Provided | Windows 10 Pro 64-bit Edition |
| Hard Drive | |
| Type | SSD - M.2 2280 |
| Capacity | 1 x 1 TB |
| Interface Type | PCI Express 3.0 x4 |
| Features | NVM Express (NVMe) |
| Dimensions & Weight | |
| Width | 6.6 in |
| Depth | 4.5 in |
| Height | 1.5 in |
| Card Reader | |
| Type | Card reader |
| Supported Flash Memory Cards | microSD |
| Processor / Chipset | |
| CPU | Intel Core i7 (11th Gen) 1165G7 |
| Max Turbo Speed | 4.7 GHz |
| Number of Cores | Quad-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Turbo Boost Technology |
